Meet Blaze Terminator
Next-Generation Wildfire/Bushfire Extinguish System
Discover the PyroSafe Blaze Terminator — your ultimate solution for advanced wildfire management. Engineered for exceptional performance, this compact and eco-friendly system offers a robust suite of detection technologies and global satellite connectivity. Ready for rapid deployment, the Blaze Terminator ensures round-the-clock readiness with a sustainable power solution that lasts up to several years. Experience the future of fire safety: versatile, reliable, and designed to protect beyond borders.
Intelligent Fire-fighting Robot
Help protect fire-fighting safety, so that rescuers are no longer in danger!
Detection Sensor Options
NIO
Next-Gen Infrared Optics with QuadSenseTM technology offers rapid fire response and superior false alarm immunity.
DR: 30-90 meters
DA: Up to 6,000 sqm/sensor
SN: 2 to 3 sensors
RT: < 3 sec
PS: Powered by the main unit
LT: N/A
IM: Mounted on the main unit
(>2m)
DE: Immediately
TR: Now available
WMN
Wireless Mesh Network
With Dryad sensors offers low-maintenance mid-range detection via LoRaWAN network.
DR: 30-2,000 meters
DA: Up to 50,000 sqm/sensor
SN: Up to 100 per Gateway
RT: < 30 sec
PS: Solar-powered, battery-free
LT: 10-15 years
IM: Mounted on the tree
(>3m recommended)
DE: 2-10 hrs
TR: Now available
DFS
Distributed Fiber Sensor based on ROTDR technologies offers reliable performance for long-range detection.
DR: 30–3,000 m/channel
DA: N/A
SN: Up to 4 channel
RT: < 3 secs/channel
PS: Powered by the main unit
LT: N/A
IM: Mounted on the tree / lay on the ground
DE: 1-10 hrs
TR: Now available
Abbreviation notes:
DR: Detection Range (meter) DA: Detection Area (square meters) SN: Recommend Sensor number
RT: Response Time (seconds) PS: Power Source LT: Lifetime (years)
IM: Installation Method DE: Deployment Effort (hrs) TR: Technical Readiness
NIO
- Fastest response to fire
- Revolutionary UV/IR technology increases the detection coverage by 2x
- High sensitivity
- Superior immunity to false alarms
- Functioning in harsh conditions
- Unparalleled reliability and durability
- Multiple output options for maximum flexibility and compatibility
- Ensuring flawless operation
- Suited to meet the challenges of commercial applications
WMN
- Solutions developed by Dryad from Berlin-Brandenburg, German
- Detect forest fires during the early stages (even during the smoldering phase)
- Monitor the microclimate, measuring temperature, humidity, and air pressure
- The sensor combines ultra-low-power Air Quality sensing technology
It detects Hydrogen, Carbon Monoxide, and other gases at the p.p.m. level
- Built-in artificial intelligence for reliable detection, avoiding false alarms.
- The sensor uses LoRaWAN communications for wireless data transmission with up to 100 sensors for each gateway
- Low-maintenance with up to 15 years life span
DFS
- Distributed optical fiber sensing system based on “ARM+FPGA” architecture
- Sensing technology is based on Raman optical time domain reflectometry (ROTDR) technology
- Able to detect multiple fire points within a single fiber
- Provides excellent, stable, and reliable performance
- Positioning accuracy of 0.05m and temperature accuracy of ±0.1℃
- Fiber optics are a cost-effective and promising sensing technology
- The most economical and effective large-area fire detection solution
F-500 Firefighting Agent
PyroSafe Blaze Terminator use F-500 encapsulate agent as the firefighting agent. F-500 is the next generation, eco-friendly, fluorine free, reliable and most versatile firefighting agent available.
.png){kind=small}
Encapsulating technology
When admixed to water, F-500 EA forms stable, spherical micelles (in accordance with NFPA 18A), encapsulating fuels and flammable substances on a molecular level, permanently rendering them nonflammable and non-ignitable. Fires loose their fuels as a result of this innovative technology. Also, toxins, smoke, and soot are encapsulated within the stable, spherical micelles (e.g. fluorine compounds with battery fires)
.png){kind=small}
Superior cooling
F-500 EA reduces the evaporating temperature of water to 70 °C by impacting the hydrogen bonds of water. Heat energy from fires dissipates rapidly, surfaces and structures cool down substantially quicker.
.png){kind=small}
Surface tension
F-500 EA reduces the surface tension of water by more than 50%. This creates smaller water droplets, increasing the available water surface for cooling and encapsulation. The reduced surface tension also allows for highly improved surface penetration and surface activity of the extinguishing water, helping F-500 EA to spread quicker and get to where it is needed.
The F-500 EA concentrate is admixed to water at a ratio of 0.1% to 3%, depending on application.
Effective on 98% of fires
Save up to 80% water
Encapsulates fuels, gases, and toxins
Superior heat dissipation and cooling properties
Eco-friendly, non-hazardous and readily biodegradable
F-500 EA is approved for use to extinguish Class A and Class B fires according to DIN EN2 (MPA Dresden, SP83/08), also according to UL and NFPA (“Encapsulator Agent” in accordance with NFPA 18A). It is approved for maritime use by RINA and is MED-certified (“Wheelmark”). F-500 EA complies with legal standards with regards to safety, toxicity and hygiene. It is fluorine free, non-toxic, nonhazardous, and eco-compatible. F-500 EA is readily biodegradable (OECD 306 & OECD 301b) and REACH compliant. Up to 3% admixture of F-500 EA to water is non-hazardous and meets the German Water Hazard Classification of 0 (VwVwS 1999, version dated 2005). There is no fire extinguishing agent with a lower water hazard classification. Non-hazardous waste under RCRA CFR261.
Control and Connection
The PyroSafe Blaze Terminator is designed with versatile operational modes to ensure comprehensive, adaptive fire management in any scenario. Through global connectivity, we ensure control and monitoring can be performed anytime, anywhere, to maximize the protection of our most precious assets and planet.
Auto-detection and Alert Mode
Leveraging advanced detection technologies, the Blaze Terminator autonomously identifies wildfire threats from near to far distances—up to several kilometres. Upon detection, it promptly sends early alert signals via satellite to the management centre or the associated emergency firefighting service. This mode ensures timely awareness and readiness to tackle wildfires before they escalate.
Autonomous Activation Mode
In scenarios where no immediate human response is available, the Blaze Terminator is equipped to act independently. The system autonomously activates its firefighting mechanisms
to address and suppress the fire immediately, minimizing damage and potential escalation without waiting for
human intervention.
On-site Manually Activation Mode
Designed for versatility and immediate response, the Blaze Terminator can also be manually activated on-site by trained personnel. This mode is crucial for instances where direct human intervention is necessary, providing firefighters with an additional tool to combat fires aggressively and effectively.
Global Connectivity
Satellite IoT communication may well become the next game-changing technology in IoT. The technology has long been looked to as a viable complement to today’s cellular IoT networks, offering a backup solution for cellular connectivity and hardening the resiliency of remote and critical applications. Now, for the first time, new infrastructure, dedicated wireless communication standards, and innovative receiver hardware on our Blaze TerminatorTM are promising to bring down the cost of ownership of satellite IoT for non-terrestrial networks (NTN) solutions and grow its reach for our urgent matters.
NTN Satellite Coverage
List of Countries with Live Coverage
North America
- United States - Canada
Europe
- Austria - Belgium - Croatia
- Cyprus - Denmark - Estonia
- Finland - France - Greece
- Germany - Hungary - Ireland
- Italy - Latvia - Lithuania
- Luxembourg - Netherland - Portugal
- Slovakia - Spain - Sweden
- Switzerland - United Kingdom
Asia
- Australia - Japan - New Zealand
About Us
Stay Safe, stay Connected, Stay Protected
PyroSafe is at the forefront of fire safety innovation, dedicated to protecting lives, assets, and environments from the devastating effects of fire. Founded in Auckland, New Zealand, our mission is to blend cutting-edge technology with reliability and accessibility, creating advanced fire detection and suppression systems that set new standards in the industry. With a commitment to quality and sustainability, PyroSafe offers a range of solutions designed to meet the unique challenges of various sectors, including industrial facilities, transportation networks, and natural landscapes. Our core products, including the Blaze Terminator, ROTDR Fire Sensing System, and other sensing systems, are developed with the latest advancements in fire safety technology, ensuring comprehensive protection and peace of mind for our clients worldwide.
